Nova Pro (16K/14″) Industrial Grade LCD 3D Printer
- Using point light source technology, the lighting is more uniform.
- Servo motor - improves positioning accuracy and anti-interference ability.
- Fast and stable heating system, real-time dynamic constant temperature adjustment.
Choose options
- Using point light source technology, the lighting is more uniform.
- Servo motor - improves positioning accuracy and anti-interference ability.
- Fast and stable heating system, real-time dynamic constant temperature adjustment.
- Using point light source technology, the lighting is more uniform.
- Servo motor - improves positioning accuracy and anti-interference ability.
- Fast and stable heating system, real-time dynamic constant temperature adjustment.
| Product Name | Industrial LCD 3D Printer Machine |
| Brand/Model No. | Nova Pro (16K/14") |
| Z-axis Effective Travel | 380mm |
| Z-axis Accuracy | 0.02mm |
| LCD Screen | 14 inch 16K (15120 x 6230dpi) |
| Printing Size | 302 x 162 x 380mm |
| XY pixel accuracy | 20*26μm |
| Light Source Wavelength | 405nm (385nm optional) |
| Print Speed | 10~30mm/hr. or 1.57in./hr. (Max) |
| Layer Thickness | 0.1/0.05/0.025mm |
| Support Software | ChiTuBox, Tango |
| File Format | STL |
| Data Input | USB |
| Operating Environment | 20-30°C (advise 20-25°C) |
| Working Humidity | 50%-70% |
| Rated Power & Voltage | 1200W (220V 50HZ) |
| Printer Dimension | 530 x 438 x 1738 mm/ 68 x 21 x 17inch |
| Printer Weight | 100kg / 220lbs |
| Technology | Light curing surface forming |
| Clamshell Design | Effectively blocks UV radiation |
| Release Film |
Replaceable ACF Release Film |
3D Printing Photopolymer Resin
Standand Rigid Resin: Rigid 4000 Resin
ABS-like Resin: 280℃ High Temp Resin
Water Washable Resin: Tough 2000 Resin
8K HD Ceramic-like Resin: Tough 1500 Resin
Ultra-Clear Resin: Dental Model Ortho Resin
Rubber-like Resin: Dental Model Repaired Resin
Silicone-like Resin: Castable Wax Resin
Replacement Modules
Buid Platform: 13.6inch 7K LCD Screen
Resin Tank: 14inch 16K LCD Screen
ACF Release Film: 16inch 8K LCD Screen
After-Sale Service
- Provide the printing parameters from our original factory resin.
- Provide matched technical support and parameter pack.
- Can print upon customers' real model.
- Provide replacement repair service for damaged parts.
